Arduino Selfie




My attention is drawn towards the noise behind me....
I cannot believe it.
There it is.

  The Arduino is taking a SELFIE !!




How did this happen?

Well actually, it is not that difficult for an Arduino.

I found out that my Canon Powershot SX50 HS camera has a port on the side for a remote switch. In the "Optional Accessories" section of the camera brochure, it identifies the remote switch model as RS-60E3. I then looked up the model number on this website to find out the size of the jack (3 core, 2.5mm), and the pinout (Ground, focus and shutter) required to emulate the remote switch. Once I had this information, I was able to solder some really long wires to the jack and connect up the circuit (as described below).


And before I knew it, the Arduino was taking Selfies !!!



Warning : Any circuit you build for your camera (including this one) is at your own risk. I will not take responsibility for any damage caused to any of your equipment.


Parts Required:




Fritzing Sketch








Connection Table








Three core, 2.5 mm jack








Camera Connection to Relays








Jack pinout








Completed Circuit








Arduino Sketch



  1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38

/* ===============================================================
      Project: Arduino Selfie
       Author: Scott C
      Created: 14th Sept 2014
  Arduino IDE: 1.0.5
      Website: http://arduinobasics.blogspot.com/p/arduino-basics-projects-page.html
  Description: Arduino takes selfie every 30 seconds
================================================================== */

 /*
  Connect 5V on Arduino to VCC on Relay Module
  Connect GND on Arduino to GND on Relay Module */

 #define CH1 8   // Connect Digital Pin 8 on Arduino to CH1 on Relay Module
 #define CH3 7   // Connect Digital Pin 7 on Arduino to CH3 on Relay Module

 void setup(){
   //Setup all the Arduino Pins
   pinMode(CH1, OUTPUT);
   pinMode(CH3, OUTPUT);

   //Turn OFF any power to the Relay channels
   digitalWrite(CH1,LOW);
   digitalWrite(CH3,LOW);
   delay(2000); //Wait 2 seconds before starting sequence
 }

 void loop(){
   digitalWrite(CH1, HIGH); //Focus camera by switching Relay 1
   delay(2000);
   digitalWrite(CH1, LOW); //Stop focus
   delay(100);
   digitalWrite(CH3, HIGH); //Press shutter button for 0.5 seconds
   delay(500);
   digitalWrite(CH3,LOW); //Release shutter button
   delay(30000); //Wait 30 seconds before next selfie
 }




By connecting up the camera to an Arduino, the camera just got smarter !!
The Arduino connects to 2 different channels on the relay board in order to control the focus and the shutter of the camera. The relays are used to isolate the camera circuit from that of the Arduino. I have also included a couple of diodes and resistors in the circuit as an extra precaution, however they may not be needed.

Warning : Any circuit you build for your camera (including this one) is at your own risk. I will not take responsibility for any damage caused to any of your equipment. Do your research, and take any precautions you see fit.





The Video











If you like this page, please do me a favour and show your appreciation :

  Visit my ArduinoBasics Google + page.
Follow me on Twitter by looking for ScottC @ArduinoBasics.
Have a look at my videos on my YouTube channel.











However, if you do not have a google profile...
Feel free to share this page with your friends in any way you see fit.

433 MHz RF module with Arduino Tutorial 4:

WARNING: Please check whether you can legally use RF transmitters and receivers at your location before attempting this project (or buying the components). This project is aimed at those who are looking to automate their home.

Carrying on from my previous "433MHz transmitter and receiver" tutorials (1,2 & 3): I have thrown away the need to process the signal with a computer. This means that we can now get the Arduino to record the signal from an RF remote (in close proximity), and play it back in no time at all.

The Arduino will forget the signal when powered down or when the board is reset. The Arduino does not have an extensive memory - there is a limit to how many signals can be stored on the board at any one time. Some people have opted to create a "code" in their projects to help maximise the number of signals stored on the board. In the name of simplicity, I will not encode the signal like I did in my previous tutorials.

I will get the Arduino to record the signal and play it back - with the help of a button. The button will help manage the overall process, and control the flow of code.

Apart from uploading the sketch to the Arduino, this project will not require the use of a computer. Nor will it need a sound card, or any special libraries. Here are the parts required:




Parts Required:

Fritzing Sketch








Arduino Sketch



  1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127



/*
  433 MHz RF REMOTE REPLAY sketch
     Written by ScottC 24 Jul 2014
     Arduino IDE version 1.0.5
     Website: http://arduinobasics.blogspot.com
     Receiver: XY-MK-5V      Transmitter: FS1000A/XY-FST
     Description: Use Arduino to receive and transmit RF Remote signal
 ------------------------------------------------------------- */

 #define rfReceivePin A0     //RF Receiver data pin = Analog pin 0
 #define rfTransmitPin 4  //RF Transmitter pin = digital pin 4
 #define button 6           //The button attached to digital pin 6
 #define ledPin 13        //Onboard LED = digital pin 13

 const int dataSize = 500; //Arduino memory is limited (max=1700)
 byte storedData[dataSize]; //Create an array to store the data
 const unsigned int threshold = 100; //signal threshold value
 int maxSignalLength = 255; //Set the maximum length of the signal
 int dataCounter = 0; //Variable to measure the length of the signal
 int buttonState = 1; //Variable to control the flow of code using button presses
 int buttonVal = 0; //Variable to hold the state of the button
 int timeDelay = 105; //Used to slow down the signal transmission (can be from 75 - 135)

 void setup(){
   Serial.begin(9600); //Initialise Serial communication - only required if you plan to print to the Serial monitor
   pinMode(rfTransmitPin, OUTPUT);
   pinMode(ledPin, OUTPUT);
   pinMode(button, INPUT);
 }

 void loop(){
   buttonVal = digitalRead(button);

   if(buttonState>0 && buttonVal==HIGH){
     //Serial.println("Listening for Signal");
     initVariables();
     listenForSignal();
   }

   buttonVal = digitalRead(button);

   if(buttonState<1 && buttonVal==HIGH){
     //Serial.println("Send Signal");
     sendSignal();
   }

   delay(20);
 }


 /* ------------------------------------------------------------------------------
     Initialise the array used to store the signal
    ------------------------------------------------------------------------------*/
 void initVariables(){
   for(int i=0; i<dataSize; i++){
     storedData[i]=0;
   }
   buttonState=0;
 }


 /* ------------------------------------------------------------------------------
     Listen for the signal from the RF remote. Blink the RED LED at the beginning to help visualise the process
     And also turn RED LED on when receiving the RF signal
    ------------------------------------------------------------------------------ */
 void listenForSignal(){
   digitalWrite(ledPin, HIGH);
   delay(1000);
   digitalWrite(ledPin,LOW);
   while(analogRead(rfReceivePin)<threshold){
     //Wait here until an RF signal is received
   }
   digitalWrite(ledPin, HIGH);

   //Read and store the rest of the signal into the storedData array
   for(int i=0; i<dataSize; i=i+2){

      //Identify the length of the HIGH signal---------------HIGH
      dataCounter=0; //reset the counter
      while(analogRead(rfReceivePin)>threshold && dataCounter<maxSignalLength){
        dataCounter++;
      }
      storedData[i]=dataCounter;    //Store the length of the HIGH signal


      //Identify the length of the LOW signal---------------LOW
      dataCounter=0;//reset the counter
      while(analogRead(rfReceivePin)<threshold && dataCounter<maxSignalLength){
        dataCounter++;
      }
      storedData[i+1]=dataCounter;  //Store the length of the LOW signal
   }

     storedData[0]++;  //Account for the first AnalogRead>threshold = lost while listening for signal
     digitalWrite(ledPin, LOW);
 }


 /*------------------------------------------------------------------------------
    Send the stored signal to the FAN/LIGHT's RF receiver. A time delay is required to synchronise
    the digitalWrite timeframe with the 433MHz signal requirements. This has not been tested with different
    frequencies.
    ------------------------------------------------------------------------------ */
 void sendSignal(){
   digitalWrite(ledPin, HIGH);
   for(int i=0; i<dataSize; i=i+2){
       //Send HIGH signal
       digitalWrite(rfTransmitPin, HIGH);
       delayMicroseconds(storedData[i]*timeDelay);
       //Send LOW signal
       digitalWrite(rfTransmitPin, LOW);
       delayMicroseconds(storedData[i+1]*timeDelay);
   }
   digitalWrite(ledPin, LOW);
   delay(1000);


   /*-----View Signal in Serial Monitor
   for(int i=0; i<dataSize; i=i+2){
       Serial.println("HIGH,LOW");
       Serial.print(storedData[i]);
       Serial.print(",");
       Serial.println(storedData[i+1]);
   }
   ---------------------------------- */
 }





Now let's see this project in action !

Have a look at the video below to see the Arduino turning a light and fan on/off shortly after receiving the RF signal from the RF remote. The video will also show you how to put this whole project together - step by step.

The Video





This concludes my 433MHz transmitter and receiver tutorials (for now). I hope you enjoyed them.
Please let me know whether this worked for you or not.
I have not tested this project with other remotes or other frequencies - so would be interested to find out whether this technique can be used for ALL RF projects ??


  Loading...



If you like this page, please do me a favour and show your appreciation :

  Visit my ArduinoBasics Google + page.
Follow me on Twitter by looking for ScottC @ArduinoBasics.
Have a look at my videos on my YouTube channel.











However, if you do not have a google profile...
Feel free to share this page with your friends in any way you see fit.

ScottC 29 Jul 19:09
